1. Suitable for many kinds of pp woven roll( cold、heat cutting is optional)
2. Fixed-length, cutting according to the mark
3.Auto counting, accurate photocell eye tracking, remote control.
4.（1）cutting length 0-1600mm， and the cutting length is very precise.
（2）The Max. cutting width is 800mm
(3)the cutting speed is adjustable 20-70pcs/min
5.The bag is easy to open, not conglutinated.
|
项目Item
型号Type |
最大切袋宽度 Max. cutting width |
切割长度 Cutting length |
切割误差 Cutting precision |
切袋速度 Cutting speed |
主电机功率 Gross power |
送袋电机功率 Bag move motor power |
电热功率 Electric heating power |
主机器尺寸(mm) Installing dimensions (L×W×H)) （main） |
附机器尺寸(mm) Installing dimensions (L×W×H)) （add） |
重量 Weight |
|
QL-QDJ800 |
800mm |
10-3500mm |
±1mm |
20-70pcs/min |
2.2kw |
0.75kw |
3kw |
2500×1300×1560 |
1100×1200×1460 |
600kg |
