1. It can automatically accomplish the fixed-length thermal cutting and the bottom hemming for the woven cloth in roll, which saves labor forces.
2 .It adopts the servo motor to drive , and the optical code meter to count the length, which
precisely controls the length of bags.
3. After the heat cutting , the plackets of the bags are easy to open , not conglutinated.
4. Pneumatic up-coiling, the operation is convenient.
项目Item
型号Type |
最大卷布直径 Max. diameter Of cloth roller(mm) |
裁切长度 Cutting length(mm) |
折叠宽度 Folding width (mm) |
总功率 Gross power (kw) |
最大裁切宽度 Max. cutting width(mm) |
裁切精度 Cutting precision(mm) |
生产能力 Production capacity (pcs/m) |
安装尺寸(mm) Installing dimensions (L×W×H)(mm) |
重量 Weight(kg) |
QL-SCD-1200*800 |
1200 |
600-1200 |
20-30 |
6 |
800 |
±4mm |
20-30 |
5100×1800×1200 |
2200 |
