1. With the scroll transmission by both little cam and swing-arm wheel, the machine runs easily and stable.
2. Rolling transmission is adopted in entire structure instead of slide block and slide rod, which doesn’t need lubricant and decreases the wearing part.
3. With the detector for warp-breaking, welf-breaking and weft-ending, the sensibility for automatic stop becomes reliable.
4.. It’s an environmental product whose noise is not more than 82DB (A).
5. Low strength plastic yarn which is made from 100% regenerated plastic can be adopted to weave
6. It is high-efficient and energy economical. The highest rotation speed of the main motor can reach 180r/min and the power is 1.5/2.2kw, which can save 10 thousand degree of electricity one year compare with the old type circular loom which motor is 4KW.
项目 Item 型号 Type |
梭子数(把) number of spindle |
编织折径(mm)10-24条丝/100mm Lay-flat width(mm) (10-24warps/100mm) |
最多折丝数(条) Max.warp(pcs) |
主机转速(r/min) Rotaional speed of main body(r/min) |
主电机功率(kw) Power of main Motor(kw) |
用电总功率(kw) Total power |
产量(m/min) 40条丝/100mm (40warps/100mm) |
安装尺寸(mm) Installing dimensions (L×W×H)(mm) |
重量 Weight(kg) |
QL-PC-4/750小四梭 |
4 |
350-750 |
768 |
140-180 |
1.5/2.2 |
2/2.7 |
1.4-1.8 |
8300*2200*2730 |
1800 |
QL-PC-4/1200 中四梭 |
4 |
550-1100 |
896 |
120-160 |
2.2/4 |
2.7/4.5 |
1.2-1.6 |
8900*2350*2960 |
2000 |
QL-PC-4/1500 大四梭 |
4 |
800-1400 |
1040 |
90-125 |
4 |
4.5 |
0.9-1.25 |
9800*2500*2960 |
2300 |
